LMK20-ALU-RP Linear Motion Kit for Universal Robots UR20

The LMK20-ALU-RP, the latest Linear Motion Kit from Cobotracks, extends the range of the UR20 cobot by up to 50 metres, enhancing flexibility and efficiency. As part of the Universal Robots e-family, the UR20 is a powerful and adaptable cobot with a lightweight design (20.6 kg), a 5 kg load capacity, and an 850-mm reach. This makes it perfect for medium-duty applications, including machine tending, assembly, and pick-and-place tasks, enabling businesses to automate processes and increase productivity.

Cobotracks guarantees a simple plug & play solution thanks to the unique UR software, ensuring seamless integration and operation.

Learn more about LMK20-ALU-RP.

ROBOTTYPE
UR20/UR20e
MAX. STROKE [mm]
2.500
MAX. SPEED [mm/sec]
250
DUTY CYCLE [mm]
100
REPEATABILITY [mm]
0.05
AMBIENT TEMPERATURE [°C]
-10 °C to 60°C
ELECTRICAL INPUT
380 V
BASE WEIGHT
135 kg
WEIGHT PER 100mm STROKE
8 kg
